China's national high-tech enterprise, the leading paint spray gun supplier in the development of painting accessories.
China's national high-tech enterprise, the leading paint spray gun supplier in the development of painting accessories.
According to the viscosity of the selected fluid and the total requirements of the products we spray, the spray gun caliber can be selected from the following caliber 0.5~2.0mm. The air cap of the spray gun can be selected from round or fan-shaped. The circular angle is generally 15°, and the angle of the fan-shaped cap is generally standard 45°, 60° and 90°. The fan-shaped nozzle spray gun is not locally affected during the installation process and can be installed at any position where the air compressor can be connected.
| Model | Feed Type | Nozzle Size (mm) | Air Pressure (MPa) | Air Consumption (1/min) | 0utput (ml/min) | Spray Width | Color |
| A-S2-C2-08P | Pressure feed | 0.8 | 0.35-0.6 | 650 | 400 | 320 | Blue/Color |
| A-S2-C2-10P | 1 | 680 | 600 | 380 | |||
| A-S2-C2-13P | 1.3 | 750 | 850 | 515 | |||
| A-S2-C2-15P | 1.5 | 800 | 1100 | 980 | |||
| A-S2-C2-18P | 1.8 | 820 | 1350 | 1200 | |||
| A-S2-C2-20P | 2 | 860 | 1450 | 1550 | |||
| Nozzle* needle material:316 stainless steel | Gun body material: aluminum alloy | ||||||
