Product Description

EB combines the advantages of air suspension and bearing rotary cup electrostatic spray gun,uses gas suspension to quickly produce fine atomization characteristics,combines the bearing’s durable and stable characteristics,and increases the friction coefficient to reduce the number of hardware contacts in air suspension=the same delicate Paint particles to ensure efficient transfer of paint.Applying this principle to the spraying process,the surface of the product can be evenly coated,the gloss is high,and the electrostatic ions are evenly distributed,so that the adhesion of the coating is more uniform.

Product Parameters

All the data in the table are collected from CNISOO / CNSEIKO laboratory. The test fluid is tap water with PH = 7, the coating pressure is 1Bar, and the pipeline is directly connected. The atomized particle data is laser diffraction.

写点什么 ...

Model:E-Bell
Perforance parameter
Rotating cup diameter	Maximum speed	Use voltage	Atomizing air consumption	Rotating air consumption	Paint discharge	Spray distance	Dimensions	Weight
Φ 32mm/Φ 50mm/Φ 60mm/Φ 70mm	650000 rрm	0-60ky	20-500 NL/min	100-1000 NI/min	0-300 cc/min	200-300 mm	100-500 mm	2.78kg

Spray gun features

Features of rotating cup automatic electrostatic spray gun

● EB Rotary cup electrostatic spraying machine high-speed centrifugal force atomization,uniform spray width and electrostatic repellency atomization can obtain the best coating quality,and has a very high painting efficiency;

● Save paint,improve production efficiency,reduce coating pollution and improve working environment;

● Rotating cup automatic electrostatic spray gun、with light weight and small volume,can be automatically sprayed with reciprocating machine and robot;

● Rotating cup electrostatic spray gun is easy maintain、the protective sleeve of pipeline and spray gun can prevent the pollution of spray gun and pipeline,and the circular appearance is easy to clean;

● The product quality is reduced,only2.78kg,the adjustment range is expanded;

● The motor is reduced in volume,noise is reduced,and the speed is up to 65,000 rpm.

● The paint three-way control valve is built in,and the control is faster for aging feedback;

● Double-layer cup and saucer,no dead ends in the flow path,cleaning is quicker and more convenient;

● The gun body is made of anti-shock material to avoid static leakage and anti-adsorption of paint;
